Product Description
Adopting top-quality carbon fiber and high-strength aluminum alloy liner, this product is made by the application of first-class equipment and advanced fully-wrapping technology.
The carbon fiber wrapped gas cylinder is famous for its resistance to corrosion, long service life,light weight,high strength and no breakage. Currently, it is replacing the traditional metal materials gas cylinders,and is widely used in fire fighting, chemical,mining,auto industries and other new and high-tech fields.
This positive pressure air breathing apparatuses are self-containe open breathing apparatuses. This series of products,which are ideal personal breathing protectors for the fireman and emergency rescuer,are widely used in such sectors as fire fighting, chemical industry,shipping,petroleum,smelting, electricity, warehouse,lab,mine,for the fireman and emergency rescuers to perform effectually rescue and relief work under the conditions of heavy smoke,poison gas,steam and hypoxia,etc.
>>> Technical Specification
| Vol. | W.P of air cylinder | Max. air supply flow | Respiratory resistance | Alarm pressure | Net Weight | Service time for ref. |
| Exhalation | Inhalation |
| 2.0L | ≤30MPa | ≥1000L/min | ≤1000Pa | ≤500Pa | 5.5±0.5M Pa | 1.5KG | 15min |
| 3.0L | ≤30MPa | ≥1000L/min | ≤1000Pa | ≤500Pa | 5.5±0.5M Pa | 2.1KG | 25min |
| 4.7L | ≤30MPa | ≥1000L/min | ≤1000Pa | ≤500Pa | 5.5±0.5M Pa | 3.0KG | 45min |
| 6.8L | ≤30MPa | ≥1000L/min | ≤1000Pa | ≤500Pa | 5.5±0.5M Pa | 3.8KG | 60min |
| 9.0L | ≤30MPa | ≥1000L/min | ≤1000Pa | ≤500Pa | 5.5±0.5M Pa | 4.9KG | 90min |
| 12L | ≤30MPa | ≥1000L/min | ≤1000Pa | ≤500Pa | 5.5±0.5M Pa | 7.4KG | 125min |
